HP E4421B /1E5 250 kHz-3.0 GHz ESG Series Signal Generator
JPY200,000 4 stock
gen525






HP E4421B 250 kHz-3.0 GHz ESG Series Signal Generator

250KHz-3000MHz res0.01Hz Stability<+-1ppm/year Output-136-+13dBm res0.02dB acc0.5dB Swtime<30ms Reversepower50W N(f) 50ohmsSSBnoise-120dBc(20KHzoffset) Harm<30dBc NonHarm<-75dBc FM1/FM2 5Hz-10MHz Max10MHzdiv
INTsource:0.1Hz -50 kHz sin/squar/ramp/triangle/pulse,/noisePM max90rad
AM:0-100% res0.1% AM1/AM2 EXT1/EXT2 10Hz-10KHz
WideAM 400Hz-10MHz I input Pulse On/Off>80dB Rise/Fall<150ns MinWidth4us
Internal pulse generator Square Dual SinewaveMode
GP-IB 200W 133H426W432D 13.5Kg
Firmware ver:B0386
Maker price:JPY1,325,000-

•Last Calibration Date: 2-2-2011
Options Included:
•Opt 1E5 High-Stability Timebase
