ANRITSU MF2412C /003 20GHz Microwave Frequency Counter
JPY250,000 1 stock
fre123



Input 20GHz -30dBm

Input 10kHz -20dBm



Frequeny range:10Hz-20GHz
Input1:600MHz-20GHz
Input2:10MHz-1GHz(50ohms) 10Hz-10MHz(1Mohms) -33dBm-+10dBm Input2:25mV-2Vrms(50ohms) 25mV-10Vrms(1Mohms)

Connector1:N(f) 2:BNC(f) Gating:TriggerINT/EXT/Line Delay:20ns-100ms GateWidth:100ns-100ms PulseModulation:600MHz-20GHz
Width:100n-100msRep:10Hz-4MHz
CW:res0.1Hz/1.8s Input2:10mHz/1s for 1MHz Samplerate:1ms-10s 12Digits
LCD GP-IB 88H213W350D 5Kg

Maker Price:JPY778,000

OPT03:stability 5*10E-10/day
Power Code,CD-R(Operation manual)
